Gallium Arsenide (GaAs) is a semiconductor material with superior characteristics such as high frequency, high electron mobility, high output power, low noise and good linearity, which is widely used in the optoelectronics and microelectronics industries. In the field of optoelectronics industry applications, GaAs single crystal can be used to make LED (light-emitting diode), LD (laser), photovoltaic devices, etc. In the field of microelectronics industry applications, it can be used to make MESFET (Metal Semiconductor Field Effect Tube), HEMT (High Electron Mobility Transistor), HBT (Heterojunction Bipolar Transistor), IC, Microwave Diode, Hall devices, etc.
Indium Antimonide (InSb) is a compound semiconductor with exceptional characteristics, including high electron mobility, high sensitivity to infrared light, and low thermal noise. These properties make Gallium Arsenide wafer ideal for use in infrared detectors, night vision devices, and other optoelectronic applications. InSb is also used in high-speed electronics, such as high-frequency transistors and photodetectors, due to its superior performance in low-power and high-frequency operations. As a leading China Indium Antimonide wafer manufacturer, we specialize in producing high-quality InSb wafers for a wide range of applications.
Indium Antimonide Wafer Specifications
Product Name | Unit | LD Application Product Specifications | LED Application Product Specifications | Microelectronics Applications Product Specifications |
Conductive Type | n-type | p-type/n-type | - | |
Crystal Growth Methods | VGF | VGF | VGF | |
Dopant | Si | Zn/Si | Undopant | |
Diameter | inch | 2",3",4" and 6" | 2",3",4" and 6" | 2",3",4" and 6" |
Orientation(*) | (100)±0.1° | (100)±0.5° | (100)±0.5° | |
OF/IF | US or EJ | US or EJ | US, EJ or notch | |
Carrier Concentration | /cm3 | (0.4-2.5)×1018 | (0.5-5)×1019 (0.4-4)×1018 | |
Resistivity (room temperature) | ohm·cm | (1.2-9.9)×10-3 | (1.2-9.9)×10-3 | >107 |
Electron Mobility | cm2/v·s | >1500 | 50-120/>1000 | >4000 |
EPD | /cm2 | < 500 | < 5000 | < 5000 |
Laser Mark | Customised to customer requirements | Customised to customer requirements | Customised to customer requirements | |
Finished Product Thickness(*) | μm | (350-650)±25 | (350-650)±25 | (350-650)±25 |
TTV(DSP) | μm | ≤5 | ≤5 | ≤4 |
TTV(SSP) | μm | ≤10 | ≤10 | ≤10 |
Warp | μm | ≤10 | ≤10 | ≤10 |
Frontside/Backside | Side1 | Polished | Polished | Polished |
Side2 | Polished/Etched | Polished/Etched | Polished/Etched | |
out-of-the-box | Yes | Yes | Yes | |
Package | Single or multiple piece cassettes | Single or multiple piece cassettes | Single or multiple piece cassettes |
* Orientation and thickness can be customised according to customers' requirements.
Indium Antimonide Wafer Features
1. High Electron Mobility: InSb wafers have one of the highest electron mobilities among compound semiconductors, making them ideal for high-speed and high-frequency applications.
2. Infrared Sensitivity: Known for their excellent infrared absorption properties, InSb wafers are widely used in infrared detectors, thermal imaging systems, and night vision devices.
3. Low Thermal Noise: InSb has low thermal noise, making it highly suitable for precision sensors and low-noise electronics.
4. Superior Performance in Low Power: The material performs well in low-power electronic and optoelectronic devices, enhancing energy efficiency and extending device life.
5. Wide Bandgap Range: With a narrow bandgap, InSb wafers enable efficient operation at room temperature, particularly in infrared wavelength ranges.
Application Scenarios
Semiconductor silicon wafer is the upstream of integrated circuit industry and is an important material for manufacturing integrated circuits.
Semiconductor silicon wafer manufacturing technology is difficult, the downstream application is wide, the market value is high, is the main application field of silicon wafer. Silicon is the starting point of the semiconductor industry chain, through the front and back of the entire chip manufacturing process, without silicon semiconductor industry will be like water without a source. The output and quality of silicon wafers directly restricts the entire semiconductor industry, and the development of many industries such as communications, automobiles, and computers further downstream, and is a key material for manufacturing chips.
Semiconductor products are mainly used in computer, household appliances, digital electronics, electrical, communications, transportation, medical, aerospace and many other fields.
Packaging and Transportation
The packaging should be able to withstand the impact, vibration, stacking and extrusion that may be encountered during transportation, while also it has to easy to load, unload and handle.
We use professional wafer box packaging. The wafer box is protected by a double layer bag, the inside is a PE bag that can be dust-proof, and the outside is a aluminum foil bag that can be isolated from the air. The two-layer bags are vacuum-packed.
We will choose carton models according to different sizes of products. And between the product and the carton filled with shock-proof EPE foam, play a comprehensive protection.
Finally choose air transport to reach the customer's hands. This allows customers in any country and region to receive the product in the fastest time.
We comply with the Material Safety Data Sheet (MSDS) rules to ensure that the products transported are free of harmful substances and will not cause environmental pollution and explosion and other possible hazards.
